Bose FreeSpace DXA 2120 Service Manual

45
ELECTRICAL PART LIST
RCA Input PCB Assembly
Resistors
Reference
Designator
Description Vendor Part
Number
Note
R1133 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1134 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1135 10K, RMG, 1/16W, 1%, 0603/1608 4723-103J+P 4
R1136 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1137 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1138 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1139 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1140 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1141 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1142 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1143 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1144 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1145 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1146 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1147 10K, RMG, 1/16W, 1%, 0603/1608 4723-103J+P 4
R1148 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1149 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1150 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1151 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1152 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1153 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1154 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1155 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1156 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1157 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1158 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1159 10K, RMG, 1/16W, 1%, 0603/1608 4723-103J+P 4
R1160 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1161 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1162 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1163 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1164 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1165 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1166 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1167 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1168 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1169 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1170 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1171 10K, RMG, 1/16W, 1%, 0603/1608 4723-103J+P 4
R1172 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1173 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1174 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1175 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R1176 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1177 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1178 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
