Bose FreeSpace DXA 2120 Service Manual

46
ELECTRICAL PART LIST
RCA Input PCB Assembly
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R1179 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R1180 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1181 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1182 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1183 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1184 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1185 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1186 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1187 1K, RMG, 1/16W, 5%, 0603/1608 4723-102J+P 4
R1188 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1189 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1190 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1191 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1192 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1193 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1194 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1195 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1196 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1197 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1198 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1199 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1200 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1201 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1202 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1203 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1204 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1205 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1206 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1207 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1208 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1209 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1210 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1211 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1212 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1213 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1214 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1215 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1216 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1217 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1218 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1219 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1220 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1221 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1222 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1223 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1224 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
