Bose FreeSpace DXA 2120 Service Manual

47
ELECTRICAL PART LIST
RCA Input PCB Assembly
Resistors (continued)
Reference
Designator
Description Vendor Part
Number
Note
R1225 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1226 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1227 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1228 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1229 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1230 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1231 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
R1232 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1233 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1234 91 OHM, RMG, 1/16W, 5%, 0603/1608 4723-910J+P 4
R1235 634 OHM, RMG, 1/10W, 1%, 0805 4720-6340+J 4
R1236 100K, RMG, 1/16W, 5%, 0603/1608 4723-104J+P 4
Capacitors
Reference
Designator
Description Vendor Part
Number
Note
C1165 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1166 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1167 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1168 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1169 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1170 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1171 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1172 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1173 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1174 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1175 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1176 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1177 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1178 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1179 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1180 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1181 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1182 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1183 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1184 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1185 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1186 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1187 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1188 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1189 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1190 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1191 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1192 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1193 470pF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
C1194 470pF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
C1195 470pF, CC, 50V, 5%, 0603 150F-471J+P-AC 4
