Bose FreeSpace DXA 2120 Service Manual

29
ELECTRICAL PART LIST
Input/Output PCB Assembly
Resistors
Reference
Designator
Description Vendor Part
Number
Note
R101 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R102 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R103 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R104 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R105 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R106 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R107 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R108 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R109 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R110 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R111 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R112 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R113 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R114 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R115 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R116 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R117 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R118 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R119 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R120 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R121 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R122 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R123 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R124 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R125 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R126 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R127 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R128 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R129 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R130 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R131 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R132 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R133 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R134 1K, RMG, 1/16W, 1%, 0603/1608 4723-102A+P 4
R135 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R136 13K, RMG, 1/16W, 1%, 0603 4723-133A+P-R 4
R137 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R138 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R139 31.6K, RMG, 1/10W, 1%, 0805 4720-3162+J 4
R140 68K, RMG, 1/16W, 1%, 0603/1608 4723-683A+P 4
R141 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R142 1M, RMG, 1/16W, 5%, 0603/1608 4723-105J+P 4
R143 1M, RMG, 1/16W, 1%, 0603 4723-105A+P 4
R144 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R145 10K, RMG, 1/16W, 1%, 0603/1608 4723-103A+P 4
R146 200K, RMG, 1/16W, 5%, 0603/1608 4723-204J+P 4
