Bose FreeSpace DXA 2120

28
ELECTRICAL PART LIST
Miscellaneous
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
C06B WAFER, 4P, P2.0, STRAIGHT 2102-040S+003 4
CN01B 8P, ST, WAFER, P=2.0, COULOMB 2102-080S+003 4
CN02B 8P, ST, WAFER, P=2.0, COULOMB 2102-080S+003 4
CN03B 8P, ST, WAFER, P=2.0, COULOMB 2102-080S+003 4
CN04B 3P, ST, WAFER, P=2.0, COULOMB 2102-030S+003 4
CN05B 3P, ST, WAFER, P=2.0, COULOMB 2102-030S+003 4
CN06B 3P, ST, WAFER, P=2.0, COULOMB 2102-030S+003 4
CN07B CONNECTOR, FFC, 20PIN, P=1.0MM 2101-3041+0 4
CN08B CONNECTOR, FFC, 20PIN, P=1.0MM 2101-3041+0 4
CN09B CONNECTOR, FFC, 20PIN, P=1.0MM 2101-3041+0 4
CN10B 3P, ST, WAFER, P=2.0, COULOMB 2102-030S+003 4
CN11B 6 PIN, WF 2102-060S+003 4
CN12B 11P, ST, WAFER, P=2.0 2102-110S+003 4
CN13B 3P, ST, WAFER, P=2.0, COULOMB 2102-030S+003 4
J201 SHUNT, 2P, P=2.54 2101-0661+0 4
J201 WAFER, 2PIN, P=2.54, ST, 6MM 2101-1494+0 4
K201 SW, TACT, SPST, SKQNAED010, H=5, ALPS 5200-4847+0-01 4
X201 CRYSTAL OSC, 11.2896M, 3.3V, SMD 2300-3282+0 4
X203 CRYSTAL OSC, 8MHZ, HC-49/U-S 2300-2990+0 4
