Bose FreeSpace DXA 2120

27
ELECTRICAL PART LIST
LEDs
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
LED201 LED, SQ, GREEN, SML-210MT 3700-4808+G 4
LED202 LED, SQ, GREEN, SML-210MT 3700-4808+G 4
LED203 LED, SQ, GREEN, SML-210MT 3700-4808+G 4
LED204 LED, SQ, GREEN, SML-210MT 3700-4808+G 4
LED205 LED, SQ, GREEN, SML-210MT 3700-4808+G 4
Reference
Designator
Description Vendor Part Number Note
Q201 FET, J174,_NL, P-CHANNEL, IDSS-20~-100MA 490J-1740+K 4
Q202 2SC1845, FE, RLT 4860-0190+K 4
Transistors
Integrated Circuits
Reference
Designator
Description Vendor Part Number Note
U204 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U205 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U207 SN74LV245ADWR, OCTAL B TRANSCEIVER,
SOT163-1/SO
3132-0680+0 4
U208 24BIT DAC W/VOL CTRL, 20P, CS4392-KZZ,
TSSOP
3132-0730+0 4
U209 24BIT DAC W/VOL CTRL, 20P, CS4392-KZZ,
TSSOP
3132-0730+0 4
U210 CS5361-KSZ, 192KHZ A/D, SM, S01C24L 3132-0240+0 4
U211 CS5361-KSZ, 192KHZ A/D, SM, S01C24L 3132-0240+0 4
U212 DSP, TMS320D707RFP/S, PQFP144, TI 3132-3381+0 4
U213 CS5361-KSZ, 192KHZ A/D, SM, S01C24L 3132-0240+0 4
U215 SUPERVISOR, SO8, TPS3307-33DGNR,
TEXAS
3132-3016+0 4
U216 4M FLASH, S29AL004D-90TFI02, STANDARD,
TSOP48
3132-3571+0 4
U217 SN74LV245ADWR, OCTAL B TRANSCEIVER,
SOT163-1/SO
3132-0680+0 4
U218 16-CH DEMULTIPLEXER, 74HC4067M96,
SO24, TEXAS
3132-3021+0 4
U219 MAX232D, SO16 3131-9470+0 4
U220 74LCX125M, S01C 3132-0770+0 4
U221 OPTOCOUPLER, 6N137, TTL, DIP8 3132-3291+0 4
U222 MCU, ATMEGA16L, TQFP44 3132-7340+1 4
U225 8-BIT SHIFT REGISTER, 74HC166, SO-16 3132-3281+0 4
U226 8-BIT SHIFT REGISTER, 74HC166, SO-16 3132-3281+0 4
U229 BUS REGISTER, HCF4094, SO16, ST 3132-3191+0 4
U230 BUS REGISTER, HCF4094, SO16, ST 3132-3191+0 4
U231 BUS REGISTER, HCF4094, SO16, ST 3132-3191+0 4
U232 AT24C04N-10SU-2.7, SOIC-8, EEPROM 3132-1441+1 4
U651 REG, NJM78M05DL1A-#ZZZB 3132-2101+0 4
U652 REG, NCP1117ST33T3G, 3.3V, SOT-223 3132-1481+0 4
U653 LT1587CM, DDPAK, 3-LEAD, M PACKAGE 3132-3023+0 4
