Bose FreeSpace DXA 2120

50
ELECTRICAL PART LIST
RS-232 PCB Assembly
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
J301 SOCKET, DB9, D-SUB, RA, FEMALE 2113-1749+0 4
CN10A WIRE-CONN, 3P, P2.0, #24, UL1007, L=300,
WHT/BLU, F/M
7012-7770+0 4
Speaker PCB Assembly
Resistors
Reference
Designator
Description Vendor Part
Number
Note
R801 10 OHM, RCF, 1W, 5%, AL 4708-100J+1 4
R802 10 OHM, RCF, 1W, 5%, AL 4708-100J+1 4
R803 3.3K, RMG, 1/10W, 5%, 0805 4720-332J+J 4
R804 3.3K, RMG, 1/10W, 5%, 0805 4720-332J+J 4
Capacitors
Inductors
Reference
Designator
Description Vendor Part
Number
Note
L801 TT-9904, LE 1012A, 1X12TX6MM, SPRING
COIL
1806-2393+0 4
L802 TT-9904, LE 1012A, 1X12TX6MM, SPRING
COIL
1806-2393+0 4
Reference
Designator
Description Vendor Part
Number
Note
D801 LL4148, SM 4804-1480+3 4
D802 LL4148, SM 4804-1480+3 4
D803 ZENER, 1/2W, 3.3V, SMD, ROHM, UDZSTE-
173.3B (UDZS3.3B)
4837-3V31+3 4
D804 ZENER, 1/2W, 3.3V, SMD, ROHM, UDZSTE-
173.3B (UDZS3.3B)
4837-3V31+3 4
Diodes
Reference
Designator
Description Vendor Part
Number
Note
C521 0.01uF, CC, 100V, 20%, 0805 150H-103M+J-BD 4
C522 0.01uF, CC, 100V, 20%, 0805 150H-103M+J-BD 4
C801 10uF, CT, 16V, 20%, SMD, 1.6X3.2 154D-106M+3-CF 4
C802 10uF, CT, 16V, 20%, SMD, 1.6X3.2 154D-106M+3-CF 4
C803 100pF, CC, 100V, 10%, 0805, 1.2X2, NPO 150H-101K+J-BD 4
C804 100pF, CC, 100V, 10%, 0805, 1.2X2, NPO 150H-101K+J-BD 4
C805 0.01uF, CC, 100V, 20%, 0805 150H-103M+J-BD 4
C806 0.01uF, CC, 100V, 20%, 0805 150H-103M+J-BD 4
C807 0.01uF, CC, 100V, 20%, 0805 150H-103M+J-BD 4
C808 0.01uF, CC, 100V, 20%, 0805 150H-103M+J-BD 4
C811 0.1uF, CC, 250V, 10%, X7R, 1206, 1.6X3.2 150R-104K+6-CF 4
C812 0.1uF, CC, 250V, 10%, X7R, 1206, 1.6X3.2 150R-104K+6-CF 4
