Bose FreeSpace DXA 2120 Service Manual

14
ELECTRICAL PART LIST
Resistors
Control PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
R401 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R402 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R403 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R404 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R405 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R406 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R407 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R408 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 4
R409 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R410 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R411 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R412 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R413 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R414 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R415 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R416 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
R421 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R422 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R423 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R424 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R425 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R430 300 OHM, RCF, 1/4W, 5%, ATS 4705-301J+C 4
Reference
Designator
Description Vendor Part
Number
Note
C401 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C402 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C403 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C404 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C405 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C406 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C407 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C408 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C409 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C410 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C411 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C421 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C422 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C423 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C424 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C425 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C431 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C432 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C433 10uF, CE, 16V, 20%, RLT, 4X5, SSK, SHOEI 157D-106M+K-GII 4
C434 10uF, CE, 16V, 20%, RLT, 4X5, SSK, SHOEI 157D-106M+K-GII 4
Capacitors
