Bose FreeSpace DXA 2120 Service Manual

36
Resistors
ELECTRICAL PART LIST
Amplifier PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
R501 27K, RCF, 1/4W, 5%, ATS 4705-273J+C 4
R502 27K, RCF, 1/4W, 5%, ATS 4705-273J+C 4
R503 4.7K, RCF, 1/4W, 5%, AT 4705-472J+C 4
R504 4.7K, RCF, 1/4W, 5%, AT 4705-472J+C 4
R505 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R506 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R507 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R508 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 4
R509 43K, RCF, 1/4W, 5%, ATS 4705-433J+C 4
R510 43K, RCF, 1/4W, 5%, ATS 4705-433J+C 4
R511 330 OHM, RCF, 1/4W, 5%, AT 4705-331J+C 4
R512 330 OHM, RCF, 1/4W, 5%, AT 4705-331J+C 4
R513 680 OHM, RCF, 1/4W, 5%, AT 4705-681J+C 4
R514 680 OHM, RCF, 1/4W, 5%, AT 4705-681J+C 4
R515 330 OHM, RCF, 1/4W, 5%, AT 4705-331J+C 4
R516 330 OHM, RCF, 1/4W, 5%, AT 4705-331J+C 4
R517 680 OHM, RCF, 1/4W, 5%, AT 4705-681J+C 4
R518 680 OHM, RCF, 1/4W, 5%, AT 4705-681J+C 4
R519 360 OHM, RCF, 1/4W, 5%, AT 4705-361J+C 4
R520 360 OHM, RCF, 1/4W, 5%, AT 4705-361J+C 4
R521 43K, RCF, 1/4W, 5%, ATS 4705-433J+C 4
R522 43K, RCF, 1/4W, 5%, ATS 4705-433J+C 4
R523 22K, RCF, 1/4W, 5%, ATS 4705-223J+C 4
R524 22K, RCF, 1/4W, 5%, ATS 4705-223J+C 4
R525 100 OHM, RCF, 1/4W, 5%, AT 4705-101J+C 4
R526 100 OHM, RCF, 1/4W, 5%, AT 4705-101J+C 4
R527 560 OHM, RCF, 1/4W, 5%, AT 4705-561J+C 4
R528 560 OHM, RCF, 1/4W, 5%, AT 4705-561J+C 4
R529 680 OHM, RCF, 1/4W, 5%, AT 4705-681J+C 4
R530 680 OHM, RCF, 1/4W, 5%, AT 4705-681J+C 4
R531 180 OHM, RCF, 1/4W, 5%, AT 4705-181J+C 4
R532 180 OHM, RCF, 1/4W, 5%, AT 4705-181J+C 4
R533 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R534 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R535 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R536 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R537 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R538 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R539 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R540 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R541 220 OHM, RCF, 1/4W, 5%, AT 4705-221J+C 4
R542 220 OHM, RCF, 1/4W, 5%, AT 4705-221J+C 4
R543 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R544 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R545 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
R546 10 OHM, RCF, 1/4W, 5%, ATS 4705-100J+C 4
