Bose FreeSpace DXA 2120 Service Manual

12
MAIN PART LIST
FreeSpace
®
DXA 2120 Amplifier/Mixer (see Figure 2)
Item
Number
Description
V
endor Part Number Bose
®
Part
Number
Qty. Note
1 TOP COVER, CHASSIS 1405-8601+0 298705 1
2 DSP/MCU PCB ASSEMBLY SVC-MIXER14+DSP 298689 1 2
3 BRACKET FOR DSP PCB 4135-6371+0 - 1 4
4 POWER SUPPLY PCB ASSY SVC-MIXER14+PSU 298690 1 2
5 FUSE HOLDER 4153-1100+0 - 1 3,4
6 AC JACK, IEC POWER 2113-3050+0 - 1 3,4
7 SHIELD PLATE, RCA JACK 1454-2530+0 - 1 4
8 I/O PCB ASSEMBLY SVC-MIXER14+I/O 298701 1 2
9 RCA IN/A-D BUFF PCB ASSY
(PART OF ITEM 8 ABOVE)
SVC-MIXER14+RCA - 1 2
10 CHASSIS 1405-8704+0 - 1 4
11 RS-232 PCB ASSEMBLY SVC-MIXER14+232 298702 1 2
12 RACK EAR 4135-6291+0 298706 2
13 SPEAKER PCB ASSEMBLY SVC-MIXER14+SPK 298700 1 2
14 AC VOLT SELECT PCB ASSY SVC-MIXER14+VOLT 298699 1 2
15 FRONT PANEL CONTROL
AND DISPLAY PCB ASSY
SVC-MIXER14+CTRL 298685 1 2
16 FRONT PANEL, CHASSIS 1405-9502+0 - 1
17 LIGHT PIPE 4155-1861+0 298517 9
18 FRONT PANEL, FIXED SIDE
WITH END CAP
SVC-MIXER14+CAP 298683 1
19 FRONT PANEL, ALUM, RT 1405-8901+0 - 1
20 KNOB, INPUT VOLUME
(INCLUDES ALL 4 KNOBS)
SV
C
-MIXER14+KNOB 328113-
001S
4
21 DOOR ASSEMBLY SVC-MIXER14+DOOR 298682 1
2
2
MAGNET, DOOR ASSY 4110-0001+0 2 4
23 END CAP, FRONT PANEL,
LEFT SIDE
1467-6401+0 298681 1
24 FRONT PANEL, LEFT 1467-6301+0 - 1
2
5
SPRING PLATE 4135-6381+0 - 2
26 COVER FOR SPRING 4155-1911+0 - 2
27 KNOB, PUSH 2447-3201+0 - 1
28 AC INPUT XFMR (120/240V) 1806-3927+0 298698 1 3
28 AC INPUT XFMR (100V) 1806-3928+0 301561 1 3
29 24V BACKUP P/S PCB ASSY SVC-MIXER14+DC24 298693 1 2
30 HEATSINK FOR DC-DC PCB 5400-9761+0 - 1 4
31 BRA
C
KET, FAN GUIDE 4135-6281+0 - 1 4
32 OUTPUT XFMR, CV, 70/100V 1806-3943+0 298697 2 3
