Bose FreeSpace DXA 2120 Service Manual

52
ELECTRICAL PART LIST
Volt PCB Assembly
Capacitors
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
C1 4700pF, 400V, DE7150F472MVA1KC 8910-0049+0 4
Reference
Designator
Description Vendor Part
Number
Note
J1 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J2 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J3 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J4 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J5 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J6 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J7 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J8 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
J9 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
NTC1 NTC THERMISTER, SCK057 5202-0001+0 4
NTC1 SHRINKAGE TUBE, ID=1MM, UL 1660-0890+0 4
SW2 SW, POWER, DPDT, 250V, 10A, SL14-22AM 5200-4942+0 4
