ELECTRICAL PART LIST
Speaker PCB Assembly
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
CN15B WIRE-CONN, 2P, P2.0, #24, UL1007, L=300,
WH/BU, F/M
7012-7780+0 4
CN801B WIRE-CONN, 3P, P2.0, #24, UL1007, L=300,
WHT/BLU, F/M
7012-7770+0 4
J501 5 POLE SPEAKER TERMINAL 2113-1335+0 4
J502 5 POLE SPEAKER TERMINAL 2113-1335+0 4
J503 TERMINAL-SPEAKER, 2P, P10 2113-3152+0 4
JD801 ANTENNA WASHER 4131-7701+0 4
JD802 ANTENNA WASHER 4131-7701+0 4
JP501 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP502 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP503 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP504 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP505 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP506 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP507 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP508 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP509 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP510 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP511 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP512 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP513 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP514 E641BL-2, TYPE 187 TERMINAL 4133-2380+0 4
JP515 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
JP516 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
RLY501 RELAY, 24V, 8A, 2P2T 4500-0730+0 4
