Bose FreeSpace DXA 2120 Service Manual

17
ELECTRICAL PART LIST
Resistors
DC24 PCB Assembly
Reference
Designator
Description Vendor Part
Number
Qty. Note
R701 100 OHM, RCF, 1/4W, 5%, ATS 4705-101J+C 1 4
R702 10K, RCF, 1/4W, 5%, ATS 4705-103J+C 1 4
R703 15K, RCF, 1/4W, 5%, ATS 4705-153J+C 1 4
R704 4.7K, RCF, 1/4W, 5%, ATS 4705-472J+C 1 4
R705 4.7K, RCF, 1/4W, 5%, ATS 4705-472J+C 1 4
R706 4.7K, RCF, 1/4W, 5%, ATS 4705-472J+C 1 4
R708 15K, RCF, 1/4W, 5%, ATS 4705-153J+C 1 4
R710 150K, RCF, 1/4W, 5%, ATS 4705-154J+C 1 4
R711 24K, RCF, 1/4W, 5%, ATS 4705-243J+C 1 4
R712 3.3K, RCF, 1/4W, 5%, ATS 4705-332J+C 1 4
R713 3.3K, RCF, 1/4W, 5%, ATS 4705-332J+C 1 4
R714 4.7K, RCF, 1/4W, 5%, ATS 4705-472J+C 1 4
R715 4.7K, RCF, 1/4W, 5%, ATS 4705-472J+C 1 4
R716 47 OHM, RCF, 1/4W, 5%, ATS 4705-470J+C 1 4
R717 47 OHM, RCF, 1/4W, 5%, ATS 4705-470J+C 1 4
R718 22 OHM, RCF, 1/2W, 5%, ATS 4707-220J+C 1 4
R719 22 OHM, RCF, 1/2W, 5%, ATS 4707-220J+C 1 4
R720 22 OHM, RCF, 1/2W, 5%, ATS 4707-220J+C 1 4
Capacitors
Reference
Designator
Description Vendor Part
Number
Qty. Note
C701 220uF, CE, 6.3V, 20%, RLT, 5X11,
SHOEI
157B-227M+K-IUI 1 4
C702 1000pF, CC, 50V, T-10%, 5X5, RLT,
335321025T
150F-102K+K-II 1 4
C703 47uF, CE, 35V, 20%, RLT, P5.0, 5X11,
YK, RUBYCON
157Q-476M+K-IUY 1 4
C704 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
C705 0.0047uF, CC, 50V, 10%, AT, 3.8x2.5,
MONO
150F-472K+2-GD 1 4
C706 0.0047uF, CC, 50V, 10%, AT, 3.8x2.5,
MONO
150F-472K+2-GD 1 4
C707 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
C708 2200uF, CE, 35V, 20%, RL, 16x31.5 157Q-228M+5-5$ 1 4
C709 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
C710 1000pF, CC, 50V, T-10%, 5X5, RLT,
335321025T
150F-102K+K-II 1 4
C711 100uF, CE, 50V, 20%, RLT, 8X12 157F-107M+K-OW 1 4
C712 100uF, CE, 50V, 20%, RLT, 8X12 157F-107M+K-OW 1 4
C713 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
C714 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
C715 100uF, CE, 50V, 20%, RLT, 8X12 157F-107M+K-OW 1 4
C716 100uF, CE, 50V, 20%, RLT, 8X12 157F-107M+K-OW 1 4
C717 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
C718 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 1 4
