Bose FreeSpace DXA 2120 Service Manual

35
ELECTRICAL PART LIST
Input/Output PCB Assembly
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Note
U101 AUDIO OP-AMP, OPA1632D, SO-8, TI 3132-3321+0 4
U102 AUDIO OP-AMP, OPA1632D, SO-8, TI 3132-3321+0 4
U103 AUDIO OP-AMP, OPA1632D, SO-8, TI 3132-3321+0 4
U104 AUDIO OP-AMP, OPA1632D, SO-8, TI 3132-3321+0 4
U105 DUAL OP-AMP, NJM2068M-#ZZZB 3130-6890+0 4
U106 DUAL OP-AMP, NJM2068M-#ZZZB 3130-6890+0 4
U107 AUDIO OP-AMP, OPA1632D, SO-8, TI 3132-3321+0 4
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
CHASSIS WIRE-CONN, 1P, #18, UL1015, L=200, YL/GN,
5MM, RING-TERM
7012-7850+0 4
CN04A WIRE-CONN, 3P, P2.0, #24, UL1007, L=160,
WHT/BLU, F/M
7012-7771+0 4
CN05A WIRE-SHIELD, 3P/2C, P2.0, #26, UL2547,
L=320, BLK, F/M
7012-7750+0 4
CN11A WIRE-CONN, 6P, P2.0, #24, UL1007, L=270,
F/M
7012-7760+0 4
CN20A WIRE-CONN, 3P, P2.0, #24, UL1007, L=160,
WHT/BLU, F/M
7012-7771+0 4
J101 JACK, 2 RCA, P15, H=10+9.5 2113-3153+0 4
J102 JACK, 2 RCA, P15, H=10+9.5 2113-3153+0 4
J103 JACK, 2 RCA, P15, H=10+9.5 2113-3153+0 4
J104 JACK, 2 RCA, P15, H=10+9.5 2113-3153+0 4
J111 SOCKET, EURO BLOCK, 3P, P5, ST, GREEN 2113-3144+0 4
J112 SOCKET, EURO BLOCK, 3P, P5, ST, GREEN 2113-3144+0 4
J113 SOCKET, EURO BLOCK, 3P, P5, ST, GREEN 2113-3144+0 4
J114 SOCKET, EURO BLOCK, 3P, P5, ST, GREEN 2113-3144+0 4
J115 SOCKET, EURO BLOCK, 4P, P5, ST, GREEN 2113-3148+0 4
J116 SOCKET, EURO BLOCK, 4P, P5, ST, GREEN 2113-3148+0 4
J118 SOCKET, EURO BLOCK, 3P, P5, ST, GREEN 2113-3144+0 4
J119 SOCKET, EURO BLOCK, 6P, P5, ST, GREEN 2113-3150+0 4
JP101A HEADER, 7P, P2.54, STRAIGHT, FEMALE 2101-3168+0 4
JP102A HEADER, 7P, P2.54, STRAIGHT, FEMALE 2101-3168+0 4
JP103A HEADER, 7P, P2.54, STRAIGHT, FEMALE 2101-3168+0 4
JP104A HEADER, 7P, P2.54, STRAIGHT, FEMALE 2101-3168+0 4
JP105A HEADER, 7P, P2.54, STRAIGHT, FEMALE 2101-3168+0 4
JP106A WIRE-CONN, 8P, P2.0, #24, UL01007, L=90,
F/M
7012-8770+0 4
SW101 SW, SLIDE, 4P2T, SSSF040800, ALPS/ALPHA 5200-4900+0-09 4
SW102 SW, SLIDE, 4P2T, SSSF040800, ALPS/ALPHA 5200-4900+0-09 4
SW103 SW, SLIDE, 4P2T, SSSF040800, ALPS/ALPHA 5200-4900+0-09 4
SW104 SW, SLIDE, 4P2T, SSSF040800, ALPS/ALPHA 5200-4900+0-09 4
