Bose FreeSpace DXA 2120 Service Manual

34
ELECTRICAL PART LIST
Input/Output PCB Assembly
Capacitors (continued)
Inductors
Reference
Designator
Description Vendor Part
Number
Note
C1150 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1151 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1152 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1153 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1154 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1155 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1156 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1157 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1158 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1159 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1160 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1161 1000pF, CC, 50V, T-10%, 5X5, RLT 150F-102K+K-II 4
C1162 1000pF, CC, 50V, T-10%, 5X5, RLT 150F-102K+K-II 4
C1163 1000pF, CC, 50V, T-10%, 5X5, RLT 150F-102K+K-II 4
C1164 1000pF, CC, 50V, T-10%, 5X5, RLT 150F-102K+K-II 4
C1165 1000uF, CE, 16V, 20%, RL, 10x16 157D-108M+5-S5 4
C1166 1000uF, CE, 16V, 20%, RL, 10x16 157D-108M+5-S5 4
Reference
Designator
Description Vendor Part
Number
Note
L803 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630+0 4
L804 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630+0 4
L805 FERRITE BEAD, 125 OHM, SMD, ACB453215 1802-0630+0 4
Reference
Designator
Description Vendor Part
Number
Note
D101 BAV99, SOT23, PHILIPS 4840-8970+3 4
D102 BAV99, SOT23, PHILIPS 4840-8970+3 4
D103 BAV99, SOT23, PHILIPS 4840-8970+3 4
D104 BAV99, SOT23, PHILIPS 4840-8970+3 4
D111 BAV99, SOT23, PHILIPS 4840-8970+3 4
D112 BAV99, SOT23, PHILIPS 4840-8970+3 4
D113 BAV99, SOT23, PHILIPS 4840-8970+3 4
D114 BAV99, SOT23, PHILIPS 4840-8970+3 4
D121 BAV99, SOT23, PHILIPS 4840-8970+3 4
D122 BAV99, SOT23, PHILIPS 4840-8970+3 4
D123 BAV99, SOT23, PHILIPS 4840-8970+3 4
D124 BAV99, SOT23, PHILIPS 4840-8970+3 4
D131 BAV99, SOT23, PHILIPS 4840-8970+3 4
D132 BAV99, SOT23, PHILIPS 4840-8970+3 4
D133 BAV99, SOT23, PHILIPS 4840-8970+3 4
D134 BAV99, SOT23, PHILIPS 4840-8970+3 4
D141 BAV99, SOT23, PHILIPS 4840-8970+3 4
D142 BAV99, SOT23, PHILIPS 4840-8970+3 4
D151 BAV99, SOT23, PHILIPS 4840-8970+3 4
D152 BAV99, SOT23, PHILIPS 4840-8970+3 4
Diodes
