Bose FreeSpace DXA 2120 Service Manual

33
ELECTRICAL PART LIST
Input/Output PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C197 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C198 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C199 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C200 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C1101 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1102 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1103 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1104 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1105 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1106 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1107 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1108 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1109 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1110 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1111 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1112 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1113 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1114 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1115 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1116 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1119 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1120 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1121 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1122 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1123 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1124 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1125 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1126 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1127 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1129 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1130 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1131 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1132 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C1133 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1134 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C1139 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1140 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C1141 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1142 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1143 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1144 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1145 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1146 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1147 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1148 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
C1149 47pF +/-20%, EMI FIL, DSN6NC51H470Q55B 8910-0487+0 4
