Bose FreeSpace DXA 2120

49
ELECTRICAL PART LIST
RCA Input PCB Assembly
Capacitors (continued)
Reference
Designator
Description Vendor Part
Number
Note
C1240 1000uF, CE, 16V, 20%, RL, 10x16 157D-108M+5-S5 4
C1241 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1242 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1243 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
C1244 22pF, CC, 50V, 10%, 0603/1608, 1x2 150F-220K+P-AC 4
Integrated Circuits
Reference
Designator
Description Vendor Part
Number
Note
U108 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U109 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U110 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U111 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U112 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U113 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U114 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U115 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U116 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
U117 NJM2068M-#ZZZB, DUAL OP-AMP 3130-6890+0 4
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
CN01A WIRE-CONN, 8P, P2.0, #24, UL01007, L=90,
F/M
7012-8770+0 4
CN02A WIRE-CONN, 8P, P2.0, #24, UL01007, L=90,
F/M
7012-8770+0 4
CN03A WIRE-CONN, 8P, P2.0, #24, UL01007, L=90,
F/M
7012-8770+0 4
JP101B HEADER, 7P, P2.54, STRAIGHT, MALE 2101-3167+0 4
JP102B HEADER, 7P, P2.54, STRAIGHT, MALE 2101-3167+0 4
JP103B HEADER, 7P, P2.54, STRAIGHT, MALE 2101-3167+0 4
JP104B HEADER, 7P, P2.54, STRAIGHT, MALE 2101-3167+0 4
JP105B HEADER, 7P, P2.54, STRAIGHT, MALE 2101-3167+0 4
JP106B 8P, ST, WAFER, P=2.0, COULOMB 2102-080S+003 4
