Bose FreeSpace DXA 2120

26
ELECTRICAL PART LIST
Capacitors (continued)
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
C666 470uF, CE, 10V, 20%, RLT, 8X11.5, ELNA 157C-477M+K-OVK 4
C667 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C668 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C669 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C670 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C671 100uF, CE, 16V, 20%, RLT, 6.5x7, ELNA 157D-107M+K-LMK 4
C672 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C673 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C674 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C675 100uF, CE, 16V, 20%, RLT, 6.5x7, ELNA 157D-107M+K-LMK 4
C676 470uF, CE, 10V, 20%, RLT, 8X11.5, ELNA 157C-477M+K-OVK 4
Inductors
Reference
Designator
Description Vendor Part Number Note
L206 EMI FILTER, FERRITE CHIP, EXCCET103U,
SMD, PANASONIC
2705-0020+0 4
L651 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L652 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L653 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L654 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L655 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L656 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L657 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L658 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L659 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L660 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L661 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
L662 FERRITE BEAD, SMD, ACB453215, 125 OHM 1802-0630+0 4
Diodes
Reference
Designator
Description Vendor Part Number Note
D201 LL4148, SMD 4804-1480+3 4
D202 LL4148, SMD 4804-1480+3 4
D203 LL4148, SMD 4804-1480+3 4
D651 SMD, 1SR154-400TE25 4840-1150+0 4
D652 SMD, 1SR154-400TE25 4840-1150+0 4
D653 SMD, 1SR154-400TE25 4840-1150+0 4
