Bose FreeSpace DXA 2120

25
ELECTRICAL PART LIST
Capacitors (continued)
Digital Signal Processor (DSP) PCB Assembly
Reference
Designator
Description Vendor Part Number Note
C358 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C359 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C360 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C361 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C362 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C363 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C364 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C365 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C366 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C367 0.1uF, CE, 50V, 20%, RLT, 4X7 157F-104M+K-GMK 4
C368 0.1uF, CE, 50V, 20%, RLT, 4X7 157F-104M+K-GMK 4
C369 0.1uF, CE, 50V, 20%, RLT, 4X7 157F-104M+K-GMK 4
C370 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C371 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C372 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C373 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C374 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C375 100uF, CE, 16V, 20%, RLT, 6.5x7, ELNA 157D-107M+K-LMK 4
C376 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C377 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C378 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C379 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C380 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C381 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C382 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C383 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C384 0.1uF, CE, 50V, 20%, RLT, 4X7 157F-104M+K-GMK 4
C385 2200pF, CC, 50V, 10%, 0603, 0.8x1.6 150F-222K+P-AC 4
C393 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C394 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C395 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C396 10uF, CE, 16V, 20%, RLT, 4x7, NICHICON 157D-106M+K-GMK 4
C397 22pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-220J+P-AC 4
C398 22pF, CTC, 0/60, 5%, 0603, 0.8X1.6 15CH-220J+P-AC 4
C653 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C655 100uF, CE, 16V, 20%, RLT, 6.5x7, ELNA 157D-107M+K-LMK 4
C656 100uF, CE, 16V, 20%, RLT, 6.5x7, ELNA 157D-107M+K-LMK 4
C657 100uF, CE, 16V, 20%, RLT, 6.5x7, ELNA 157D-107M+K-LMK 4
C658 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C659 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C660 470uF, CE, 10V, 20%, RLT, 8X11.5, ELNA 157C-477M+K-OVK 4
C661 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C662 470uF, CE, 10V, 20%, RLT, 8X11.5, ELNA 157C-477M+K-OVK 4
C663 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
C664 470uF, CE, 10V, 20%, RLT, 8X11.5, ELNA 157C-477M+K-OVK 4
C665 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
