Bose FreeSpace DXA 2120 Service Manual

44
ELECTRICAL PART LIST
PSU PCB Assembly
Integrated Circuits
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
U601 LM2940T-9, NS 3131-8230+0 4
U602 REGULATOR, KIA7909PI-U/P, -9V, 1A 3131-7410+0 4
U603 REGULATOR, NJM7805FA-#ZZZB 3130-2020+2 4
U604 DUAL VOLTAGE COMPARATOR, LM393, DIP8 3131-5160+0 4
U605 DUAL VOLTAGE COMPARATOR, LM393, DIP8 3131-5160+0 4
Reference
Designator
Description
V
endor Part
Number
Note
BG601 SCREW, 3X12MM, B-TITE, BLK, ZN 2954-3012+3000 4
BG601 HEATSINK, AMP, 50X46 5400-9771+0 4
CN12A 11P, ST, WAFER, P=2.0 2102-110S+003 4
CN15A 2P, ST, WAFER, P=2.0, COULOMB 210
2
-020S+003 4
CN16B WAFER, 3 PIN, P=3.96 2101-3065+0 4
CN17B WAFER, 4P, P3.96, STRAIGHT, MALE 2101-3053+0 4
CN601 WAFER, 3 PIN, P=3.96 2101-3065+0 4
F611 FUSE, T10AH, 250V
(BOSE
®
PART NUMBER 325634-0010)
5120-0110+0 3
F611A FUSE HOLDER 4132-1011+0 4
F611B FUSE HOLDER 4132-1011+0 4
F612 FUSE, T10AH, 250V
(BOSE PART NUMBER 325634-0010)
5120-0110+0 3
F612A FUSE HOLDER 4132-1011+0 4
F612B FUSE HOLDER 4132-1011+0 4
FAN 2P, ST, WAFER, P=2.0, COULOMB 2102-020S+003 4
GND WIRE-CONN, 1P, #18, UL1015, L=370, BLK, 250-
TERMINAL
7012-7833+0 4
GND WIRE-CONN, 1P, #18, UL1015, L=430, YL/GN,
4MM, RING-TERM
7012-7851+0 4
JP601 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
JP602 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
JP603 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
JP604 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
JP605 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
JP606 SPADE TERMINAL, 6.3X0.8, STRAIGHT 2101-1231+0 4
Q601 SCREW, MACHINE, BIND HEAD, M3X8, CROSS-
RECESS, BZ
2904-3008+3000 4
Q601 HEATSINK, SMALL 5400-3741+1 4
TH611 WIRE-CONN, 2P, P2.0, #24, UL1007, L=120,
WH/BU, F/M
7012-7781+0 4
U601 SCREW, MACHINE, BIND HEAD, M3X8, CROSS-
RECESS, BZ
2904-3008+3000 4
U601 SCREW, B-TITE, BIND, M2.6X6, CROSS-
RECESS, BZ
2954-2606+3000 4
U601 HEATSINK, 23.5X17X25 5400-9141+0 4
U603 SCREW, MACHINE, BIND HEAD, M3X8, CROSS-
RECESS, BZ
2904-3008+3000 4
U603 HEATSINK, SMALL 5400-3741+1 4
