ELECTRICAL PART LIST
PSU PCB Assembly
Diodes
Transistors
Reference
Designator
Description Vendor Part
Number
Note
BG601 BRIDGE, RECTIFIER, 15A, 200V, GBJ1503 4840-9120+0 4
BG602 BRIDGE, DIODE, RS203L-B (RECTRON) 4840-1120+0 4
D601 IN4004-F, AT 4804-0040+2 4
D602 IN4004-F, AT 4804-0040+2 4
D603 IN4004-F, AT 4804-0040+2 4
D604 IN4004-F, AT 4804-0040+2 4
D605 ZENER, 1/2W, 24V, TEMIC, AT 4837-24V6+2 4
D606 1N4148T, AT 4804-1480+2 4
D607 1N4148T, AT 4804-1480+2 4
D608 ZENER, 1/2W, 5.1V, ROHM, AT 4837-5V11+2 4
D609 IN4004-F, AT 4804-0040+2 4
D610 IN4004-F, AT 4804-0040+2 4
D611 1N4148T, AT 4804-1480+2 4
D612 1N4148T, AT 4804-1480+2 4
D614 1N4148T, AT 4804-1480+2 4
D615 1N4148T, AT 4804-1480+2 4
D616 1N4148T, AT 4804-1480+2 4
D617 1N4148T, AT 4804-1480+2 4
D618 ZENER, 1/2W, +/-5%, 3.3V, TEMIC, AT 4837-3V36+2 4
D619 1N4148T, AT 4804-1480+2 4
D620 1N4148T, AT 4804-1480+2 4
D621 ZENER, 1/2W, 12V, 5%, TEMIC, AT 4837-12V6+2 4
D622 IN4004-F, AT 4804-0040+2 4
D623 IN4004-F, AT 4804-0040+2 4
D624 IN4004-F, AT 4804-0040+2 4
D625 ZENER, 1/2W, 12V, 5%, TEMIC, AT 4837-12V6+2 4
D626 IN4004-F, AT 4804-0040+2 4
D627 ZENER, 1/2W, +/-5%, 3.3V, TEMIC, AT 4837-3V36+2 4
Reference
Designator
Description Vendor Part
Number
Note
Q601 TIP41C, SGS, TO-220 4860-8470+0 4
Q602 2SC1845 (F.E) RLT 4860-0190+K 4
Q603 2SC1845 (F.E) RLT 4860-0190+K 4
Q604 TIP41C, SGS, TO-220 4860-8470+0 4
Q605 TIP41C, SGS, TO-220 4860-8470+0 4
Q606 2SC1845 (F.E) RLT 4860-0190+K 4
Q607 2SC1845 (F.E) RLT 4860-0190+K 4
Q608 FET, N-CHAN, 2N7000RLRAG/BSN10/BSN10A,
C-MOS, RLT
490S-N100+K 4
Q609 2SC1845 (F.E) RLT 4860-0190+K 4
Q610 2SC1845 (F.E) RLT 4860-0190+K 4
Q611 2SC1845 (F.E) RLT 4860-0190+K 4
