Bose FreeSpace DXA 2120 Service Manual

42
ELECTRICAL PART LIST
PSU PCB Assembly
Capacitors
Reference
Designator
Description Vendor Part
Number
Note
C601 0.01uF, CC, 100V, 20%, RLT, 5X5 150H-103M+K-II 4
C602 0.01uF, CC, 100V, 20%, RLT, 5X5 150H-103M+K-II 4
C603 0.01uF, CC, 100V, 20%, RLT, 5X5 150H-103M+K-II 4
C604 0.01uF, CC, 100V, 20%, RLT, 5X5 150H-103M+K-II 4
C605 8200uF, CE, 50V, 20%, 85C, RL, 30X42 157F-828M+5-$^ 4
C606 8200uF, CE, 50V, 20%, 85C, RL, 30X42 157F-828M+5-$^ 4
C607 8200uF, CE, 50V, 20%, 85C, RL, 30X42 157F-828M+5-$^ 4
C608 8200uF, CE, 50V, 20%, 85C, RL, 30X42 157F-828M+5-$^ 4
C609 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C610 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C611 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C612 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C613 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C614 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C615 2200uF, CE, 25V, 20%, RLT, 12.5X25 157E-228M+K-X&I 4
C616 2200uF, CE, 25V, 20%, RLT, 12.5X25 157E-228M+K-X&I 4
C617 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C618 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C619 470uF, CE, 25V, 20%, RLT, 10X12.5, ELNA 157E-477M+K-SXE 4
C620 470uF, CE, 25V, 20%, RLT, 10X12.5, ELNA 157E-477M+K-SXE 4
C621 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C622 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C623 1000uF, CE, 16V, RLT, 10X16, RE3, ELNA 157D-108M+K-S5E 4
C624 0.1uF, CC, 50V, 10%, RLT, 5x5 150F-104K+K-II 4
C625 22uF, CE, 50V, 20%, RLT, 5X11 157F-226M+K-IU 4
C626 22uF, CE, 50V, 20%, RLT, 5X11 157F-226M+K-IU 4
C627 0.01uF, CC, 100V, 20%, RLT, 5X5 150H-103M+K-II 4
C631 22uF, CE, 50V, 20%, RLT, 5X11 157F-226M+K-IU 4
C632 2.2uF, CE, 50V, 20%, RLT, 5X11 157F-225M+K-IU 4
C633 100uF, CE, 35V, 20%, RLT, 6.3X11, SHOEI 157Q-107M+K-LUI 4
C634 100uF, CE, 35V, 20%, RLT, 6.3X11, SHOEI 157Q-107M+K-LUI 4
C635 2.2uF, CE, 50V, 20%, RLT, 5X11 157F-225M+K-IU 4
C636 2.2uF, CE, 50V, 20%, RLT, 5X11 157F-225M+K-IU 4
C637 4.7uF, CE, 50V, 20%, RLT, 5X11, ELNA 157F-475M+K-IUE 4
C638 22uF, CE, 50V, 20%, RLT, 5X11 157F-226M+K-IU 4
