Bose FreeSpace DXA 2120 Service Manual

31
ELECTRICAL PART LIST
Input/Output PCB Assembly
Capacitors
Reference
Designator
Description Vendor Part
Number
Note
C101 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C102 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C103 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C104 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C105 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C106 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C107 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C109 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C110 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C111 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C112 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C113 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C114 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C115 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C116 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C117 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C118 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C119 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C120 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C121 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C122 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C123 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C124 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C125 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C126 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C129 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C130 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C131 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C132 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C133 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C134 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C135 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C136 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C137 EMI FILTER, NFM21CC102R1H3D 2705-0040+0 4
C138 EMI FILTER, NFM21CC102R1H3D 2705-0040+0 4
C139 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C140 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C141 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C142 1000pF, CC, 50V, 5%, 0603, X7R 150F-102J+P-AC 4
C143 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C144 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C145 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C146 10pF, CC, 50V, 5%, 0603 150F-100J+P-AC 4
C147 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C148 10uF, CE, 16V, 20%, SMD, 4X5.4 157D-106M+3-GJ 4
C149 0.1uF, CC, 50V, 10%, 0603/1608, 1x2 150F-104K+P-AC 4
