Bose FreeSpace DXA 2120 Service Manual

38
Capacitors
ELECTRICAL PART LIST
Amplifier PCB Assembly
Inductors
Reference
Designator
Description Vendor Part
Number
Note
C501 10uF, CE, 16V, 20%, RLT, ELNA 157D-106M+K-GMK 4
C502 10uF, CE, 16V, 20%, RLT, ELNA 157D-106M+K-GMK 4
C503 68pF, CC, 50V, 5%, RLT 150F-680J+K-IF 4
C504 68pF, CC, 50V, 5%, RLT 150F-680J+K-IF 4
C505 470pF, CC, 50V, 10%, AT 150F-471K+2-FC 4
C506 470pF, CC, 50V, 10%, AT 150F-471K+2-FC 4
C507 220uF, CE, 10V, 20%, RL, ELNA 157C-227M+5-OME 4
C508 220uF, CE, 10V, 20%, RL, ELNA 157C-227M+5-OME 4
C509 15pF, CC, 50V, 5%, AT 3 150F-150J+2-FC 4
C510 15pF, CC, 50V, 5%, AT 3 150F-150J+2-FC 4
C511 33pF, CC, 50V, 10%, RLT 150F-330K+K-GG 4
C512 33pF, CC, 50V, 10%, RLT 150F-330K+K-GG 4
C513 0.022uF, CM, 50V, 5%, RLT, 6.5x9 153F-223J+K-LQ 4
C514 0.022uF, CM, 50V, 5%, RLT, 6.5x9 153F-223J+K-LQ 4
C515 10pF, CC, 50V, 5%, RLT, 5x5 150F-100J+K-II 4
C516 10pF, CC, 50V, 5%, RLT, 5x5 150F-100J+K-II 4
C517 10pF, CC, 50V, 5%, RLT, 5x5 150F-100J+K-II 4
C518 10pF, CC, 50V, 5%, RLT, 5x5 150F-100J+K-II 4
C519 0.033uF, CM, 50V, 5%, RLT, METALZD 153F-333J+K-NLM 4
C520 0.033uF, CM, 50V, 5%, RLT, METALZD 153F-333J+K-NLM 4
C523 100uF, CE, 50V, 20%, RL 157F-107M+5-OW 4
C524 100uF, CE, 50V, 20%, RL 157F-107M+5-OW 4
C525 0.01uF, CC, 100V, 20%, RLT, 5x5 150H-103M+K-II 4
C526 0.01uF, CC, 100V, 20%, RLT, 5x5 150H-103M+K-II 4
C527 100uF, CE, 50V, 20%, RL 157F-107M+5-OW 4
C528 100uF, CE, 50V, 20%, RL 157F-107M+5-OW 4
C529 2.2uF, CE, 50V, 20%, RLT 157F-225M+K-GMK 4
C530 220uF, CE, 10V, 20%, RL, NON-POLAR 157C-227M+5-OUN 4
C531 0.01uF, CC, 50V, 10% 150F-103K+2-FC 4
C532 0.01uF, CC, 50V, 10% 150F-103K+2-FC 4
C533 0.01uF, CC, 50V, 10% 150F-103K+2-FC 4
C534 0.01uF, CC, 50V, 10% 150F-103K+2-FC 4
Reference
Designator
Description Vendor Part
Number
Note
L501 FERRITE BEAD, INDUCT, BL01RN1A1F1J 1808-0680+0 4
L502 FERRITE BEAD, INDUCT, BL01RN1A1F1J 1808-0680+0 4
L503 FERRITE BEAD, INDUCT, BL01RN1A1F1J 1808-0680+0 4
L504 FERRITE BEAD, INDUCT, BL01RN1A1F1J 1808-0680+0 4
L505 FERRITE BEAD, INDUCT, BL01RN1A1F1J 1808-0680+0 4
L506 FERRITE BEAD, INDUCT, BL01RN1A1F1J 1808-0680+0 4
