Bose FreeSpace DXA 2120 Service Manual

40
ELECTRICAL PART LIST
Amplifier PCB Assembly
Transistors (continued)
Miscellaneous
Reference
Designator
Description Vendor Part
Number
Note
Q532 2SC2458-GR, RLT, HFF200~400 4852-458G+K 4
Q533 2SC2458-GR, RLT, HFF200~400 4852-458G+K 4
Q534 2SC2458-GR, RLT, HFF200~400 4852-458G+K 4
Q535 2SA1048-Y, TE4/F/T, RLT 4860-3340+K 4
Reference
Designator
Description Vendor Part
Number
Note
TH611 THERMAL, MTC, 10K, RED WIRE 5202-0003+1 4
CN06A WIRE-CONN, 4P, P2.0, #26/24,
UL2547/UL1007, L=100, F/M
7012-7790+0 4
CN501 2P, ST, WAFER, P=2.0, COULOMB 2102-020S+003 4
J604B PLATE, TERMINAL, RT 4134-2421+0 4
J605B PLATE, TERMINAL, RT 4134-2421+0 4
J606B PLATE, TERMINAL, RT 4134-2421+0 4
LOUT WIRE-CONN, 1P, #18, UL 1015, L=160,
BLU, 250-TERMINAL
7012-7835+0 4
ROUT WIRE-CONN, 1P, #18, UL 1015, L=120,
RED, 250-TERMINAL
7012-7834+0 4
PAMP SHRINKAGE TUBE, ID=1MM, UL 1660-0890+0 4
