TEST PROCEDURES

3.1 Line inputs (J111-J114) with MIC/LINE switch in LINE position

Input signal 0 dBV (1V) @ 1KHz sine wave

Output level

3.2 Mic inputs (J111-J114) with MIC/LINE switch in MIC position:

Input signal -30 dBV (31,5mV) @ 1KHz sine wave

Output level

Auxiliary Output -11.60 dBV ±0.5 dBV THD <0.1%

3.3 RCA inputs (J101-J104) with both connectors being driven:

Input signal 0 dBV (1V) @ 1KHz sine wave

Output level

Auxiliary Output -10.55 dBV ±0.5 dBV THD <0.1%

3.4 Direct input (J115)

Input signal 0 dBV (1V) @ 1KHz sine wave

Output level

Auxiliary Output -9.55 dBV ±0.5 dBV THD <0.1%

Output Level THD

4 Ohm 13.55 dBV ±0.5dBV < 0.1 %

70V (49 Ohms) 23.75 dBV ±0.5 dBV < 0.1 %

100V (98 Ohms) 26.85 dBV ±0.5 dBV < 0.1 %

Output Level THD

4 Ohm 14.55 dBV ±0.5dBV < 0.1 %

70V (49 Ohms) 24.75 dBV ±0.5 dBV < 0.1 %

100V (98 Ohms) 27.85 dBV ±0.5 dBV < 0.1 %

Output Level THD

4 Ohm 15.55 dBV ±0.5dBV < 0.1 %

70V (49 Ohms) 25.75 dBV ±0.5 dBV < 0.1 %

100V (98 Ohms) 28.85 dBV ±0.5 dBV < 0.1 %

Output Name Output Level THD

4 Ohm 14.85 dBV ±0.5dBV < 0.1 %

70V (49 Ohms) 25 dBV ±0.5 dBV < 0.1 %

100V (98 Ohms) 28 dBV ±0.5 dBV < 0.1 %
