M1 – M3 Display units
Page 49
Input/output modules
The connection of an input/output module is made with the same way than a
multiplexer.
Up to 4 MB-IO can be connected.
Example: connection of a MB-IO module on the M3.
The different options for the MB-IO configuration are displayed bellow.
Click here to
configure the MB-
IO
