M1 – M3 Display Units
Page 88
b – Temperature compensation mode
When the « compensation mode » is activated, it is requested to enter the expansion
coefficient. As an information, on the below table you can see the coefficients of the
main materials (source Wikipedia):
The compensation is done assuming that the Master part has been measured at 20°C.
If it is not the case, select the option “advanced” and a next page appear, allowing to
enter the temperature of the master during the measurement according to its certificate:
If validated (green), a
new screen appears
allowing to set the
temperature of the
master’s certificate.
Temperature indicated
on the certificate
To Next Page
