Service Manual 04/2010 Rev.B
5
1.0 INTRODUCTION
This technical manual describes maintenance,
check and repair operations of the G.S. range of
Boxer King 5600 and 5600R and is for use of
qualified personnel only.
This manual is also applicable to the following
models:
BOXER KING 5600/5600R
ACCU 4560/4560MR
HOFMANN JAPAN GX56
HOFMANN MONTY 4400/4400R
TIP TOP PROMONT 956 SUPER
EIWA WING 311
COATS 9500/9500R
Reproduction, translation and accommodation
rights are reserved.
ALL SAFETY REGULATIONS
MUST BE STRICTLY
FOLLOWED DURING ANY
MAINTENANCE, CHECK AND
REPAIR OPERATION.
PERSONNEL PERFORMING
MAINTENANCE, CHECK AND
REPAIR OPERATIONS MUST
HAVE BEEN DULY TRAINED BY
G.S. AUTHORIZED
INSTRUCTORS.
Keep this manual constantly updated, by adding
Service Bulletins related to Boxer King 2600.
IMPORTANT!
THE IDENTIFICATION DATAS OF EACH
MACHINE ARE PRINTED ON A PLATE.
UNTILL DECEMBER 31 2001, THE SERIAL
NUMBER IS A SEQUENCE OF FIGURES
STANDING FOR THE MANUFACTURING
MONTH (#1) AND YEAR (#2), FOLLOWED BY A
PROGRESSIVE NUMBER (#3) AND #4 SHOWS
THE MODEL.
STARTING FROM JANUARY 1 2002, THE
SERIAL NUMBER HAS CHANGED SEQUENCE
OF FIGURES STANDING FOR THE
MANUFACTURING MONTH (#1) AND YEAR
(#2), REFERENCE NUMBER OF THE MACHINE
(#3) AND PROGRESSIVE NUMBER OF THE
MACHINE (#5) MANUFACTURED WITH THIS
PART NUMBER.
THE #4 STILL SHOWS THE MODEL.
2.0 TOOLS
Before starting any repair operation, make sure
that all required tools are available:
1 Set of end wrenches from 8 to 30mm
Fig.1
1 Set of screwdrivers (standard and cross type).
Fig.2
