Tree topology
In TREE topology, an effort is made to take advantage of the star topology, limiting critical issues. Starting
from a “father”node, a series of devices are connected, to which other devices are connected, creating a
branched wiring structure. This reduces the amount of cable to be laid and the issue of possible breakage
of the star centre.
BUS topology:
In BUS topology, a single branch of cable interconnects all devices to one another. With this method, there
is the risk that a breakage of the cable in one point causes a breakdown of the entire system.
