Bpt mitho+ - Terminal Function

77
Technical Manual
GB
2
Terminal function
Terminal block M1
Bus Line automation
electrical
LA
Terminal block M2
R+ Connection to
R– bus RS422 for
T+ B2 anti-intrusion systems
T–
– Common earth
Terminal block M3
Power supply
12÷24 V DC
Terminal block M4
MM MultiMaster BUS
M3
M4
R+
R–
T+
T–
–
LA
M2
M1
MM
