Technical Manual
GB
Mitho multi-function video terminal
Mithoplus is the innovative colour touch screen multifunctional terminal designed for the management and
control of BPT HOME SAPIENS electric automation, Brahms anti-intrusion security and video entry control
in the X1 and 300 2-wire systems (power supply separate).
The hands-free audio and the integrated receiver allow simple, immediate communications.
1 – Loudspeaker (hands free)
2 – Receiver
3 – Microphone
4 – 4.3” touch screen 16:9 display
5 – Touchscreen pen housing
Technical Features
• 16:9 wide screen 4.3” 480x272 pixel touch screen display
• Operating temperature: from 5 °C to +40 °C.
• Power supply:
14÷24 V DC local (12÷16 V AC local).
• Absorption:
0.75 A (1.5 A peak) 12 V AC,
0.5 A (1.1 A peak) 16 V AC,
0.31 A (0.81 A peak) 18 V DC
0.23 A (0.58 A peak) 24 V DC
• Dimensions: 203x108x31 mm.
