Bpt mitho+ - Example 5: C4 Anti-Intrusion System

92
Technical Manual
GB
Example No. 5
Installation in C4 anti-intrusion systems
KEYPAD
BXTAIN01
CONTROL UNIT
C4UC0...
ROPE CONTACT
CFSST
INTERFACE CARD
SACIF
IPV INFRARED
SENSOR...
OR
SENSOR WITH
SDT DUAL
TECHNOLOGY...
GATEWAY
OH/GW
MITHO
POWER SUPPLIER
VAS/100MH
SVAMB GLASS BREAKAGE
SENSOR
SERIAL
INTERFACE
BXRS4201
Multimaster bus
Local power supply
5 wires
