Technical Manual
GB
Mitho Multi-function Video Terminal
Installation
Remove the unit from the me-
tallic support by sliding it after
pressing the plastic button ( g.
1).
Fasten the metallic support to the
round built-in box of Ø 60 mm
( g. 2A) or to the rectangular box
503 ( g. 2B), using the screws pro-
vided and complying with the UP
indication.
The recessed box must be  tted
at a suitable height in relation to
the user.
Avoid excessive tightening of
screws on walls that are not per-
fectly flat.
1
2
A
B




