63
Technical Manual
GB
Power supplier VAS/100MH
This consists of a transformer with a power of 10 VA. It is equipped with a rectifier that provides output volt-
age at 18 V DC, electronically protected against overloads and short circuits. This protection automatically
restores normal operation of the power supplier after the causes have been removed that activated the
protection.
A single power supplier is provided for systems connected to the terminal + e – of the plate and the
intercom.
PRI
SEC
Technical Features
• Power supply: 230 V AC +6% -10%, 50/60 Hz 10 VA.
• Output voltage: 18V DC, 0.5A in continuous service.
• Operating temperature: 0-35 °C.
• Dimensions: low-profile 3-unit module for installation on DIN rail
