Bpt mitho+ - Example 3: Single Family Video Entry

88
Technical Manual
GB
Example No. 3
Installation in single family video entry control system plus electrical power supply.
First  oor
Local power supply
2-wire bus X1 video entry control system bus
Multimaster bus
Automation Bus
MITHO
MITHO
AUTOMATION
POWER SOURCE
OH/A.01
GATEWAY
OH/GW
POWER SUPPLIER
VAS/100MH
AUTOMATION
POWER SOURCE
OH/A.01
GATEWAY
OH/GW
POWER SUPPLIER
VAS/100MH
Ground  oor
OH/6I
OH/3RPI
OH/Z.02
