Technical Manual
GB
Example No. 4
Installation in B2 anti-intrusion systems
B2 Anti-intrusion Bus
Multimaster bus
CONTROL PANEL
B2UC0002
KEYPAD
BXTAIN01
MODULE
WITH 2 RELAY OUTPUTS
B2MO0201
POWER SOURCE
B2AL0001
SENSOR INTERFACE
1-INPUT MODULE
WITH POWER SUPPLIER
B2MIA101
REPEATER
MODULE
B2RPAL01
SERIAL
INTERFACE
BXRS4201
GATEWAY
OH/GW
MITHO
POWER SUPPLIER
VAS/100MH
Local power supply
5 wires
