Bpt mitho+ - Example 1: X1 Video Entry System

81
Technical Manual
GB
Example No. 1
Installation in X1 video entry control systems.
MITHO
MITHO
POWER SUPPLIER
VAS/100MH
POWER SUPPLIER
VAS/100MH
POWER SUPPLIER
VA/301
OPHERA
AT ENTRY
PANEL
MITHO
POWER SUPPLIER
VAS/100MH
INTERCOM SELECTOR
VSE/301
APARTMENT 1
APARTMENT 3
VIDEO DISTRIBUTOR
XDV/304
Local power supply
2-wire bus X1 video entry control system bus
Multimaster bus
