66
Technical Manual
GB
Electric automation
• Up to 200 automation modules, to be divided into groups of a maximum of 79 modules
• (39 + BUS REPEATER MODULE + 40) for OH/GW gateway.
• Up to 20 heating zones per OH/GW gateway, either independent or centralised.
• Management of user scenarios that can be created directly from the terminal or from systems and installer
scenarios con gurable from programming software,
• Maximum number of implementations per user scenario: 30
• Maximum distance of buttons, sensors, etc. from the input devices: 20 m.
• The distance is halved to 10 m if the insulated input wires are anked by mains conductors.
• The devices are connected on 2 wires, with twisted pair NH-C1D (section 0.38 mm
2
), non-shielded with
free distribution, that manage power supply and data
Intruder prevention security
• Up to 32 system peripherals connected to security bus with a maximum of 128 inputs.
• 10 controllable areas/scenarios.
• 64 user pro les.
• For the characteristics of the anti-intrusion system, refer to the corresponding documentation.
Video entry control
• For the characteristics of the X1/300 video entry control system, refer to the corresponding documenta-
tion.
