Brady BBP 85 - System Components

2-2 BBP
®
85 Label Printer User’s Manual
Unpacking and Setting up Printer
System Components
System Components
Figure 2-1. Printer Components
Note: The printer is equipped with a universal power supply and can be operated
with a supply voltage of 100 to 240 V~, 50- to 60 Hz. The printer senses the voltage
type and automatically adjusts for the power source.
1 Keyboard 2 Stylus
3 Display (with touchscreen) 4 Power Button
5 Enclosure Cover 6 Label Exit
7 USB Ports 8 Media Wiper
9 Media 10 Media Guides
11 Cutter 12 Ribbon
3
2
5
6
12
8
10
7
11
4
9
1
