Backbone Serialization Examples (110-Block and BIX-Block Labels)
The leftmost zones on each strip print with two numbers. The first number is left-justified; the second
number is right justified. All other zones print with one right-justified number. Note: Examples below
may not be drawn exactly to scale.
Note: Rotation cannot be adjusted on 110-Block or BIX-Block labels.
Example—2 Pair
1 2 4 6 8 10 12 14 16 18 20 22 24
25 26 28 30 32 34 36 38 40 42 44 46 48
Example—3 Pair
1 3 6 9 12 15 18 21 24
25 27 30 33 36 39 42 45 48
Example—4 Pair
1 4 8 12 16 20 24
25 28 32 36 40 44 48
Example—5 Pair
1 5 10 15 20 25
26 30 35 40 45 50
Note: Non-printable zones are included on each end (0.2" at front end of strip, remainder at
end of label, varied depending on pair type).
34 User Manual
