Component Locations
46 Servicing and Maintaining Your Empulse
RIGHT-HAND SIDE OF THE EMPULSE
1. Rear brake fluid reservoir
2. Fuse box (under upper body panel)
3. High voltage connector (behind
upper body insert)
4. Rear brake caliper
5. Rear suspension spring
6. Transmission oil - drain plug
7. Transmission oil - fill plug
8. Coolant filler cap (behind front cover)
9. Front brake caliper
