If a Fuse Blows
78 Taking Care of the Unexpected
High Voltage Fuse box - Right Side
WARNING
To prevent the risk of an electric shock, always make sure that the
ignition switch is in the Off position and the key is removed. Never
work on the Empulse if the charging cable is connected.
Fuse Rating Circuit protected
1 15A/125V Charger
2 15A/125V Charger
3 15A/125V Charger
4 5A/125V Motor Controller
5 5A/125V DC/DC
