Maintenance
Servicing and Maintaining Your Empulse 51
Maintenance
BATTERY SAFETY DISCONNECT
Brammo recommends that you always disconnect the Battery Safety
Disconnect before working on any of the electrical systems.
To disconnect the Battery Safety Disconnect:
1. Remove the upper body insert See “
UPPER BODY INSERT”,
page 49.
2. Remove the front cover See “
FRONT COVER”, p a g e 5 0 .
3. Locate the upper and lower halves of the Battery Safety
Disconnect.
4. Reaching up from the underside of the frame, locate the blue
button on the connector.
5. Press the button and separate the two halves of the connector.
6. Position the two halves of the connector outside the frame as a
visual reminder to reconnect it when work is complete.
Reconnection
To reconnect the Battery Safety Disconnect, position the two halves
of the connector in the frame and then fully insert the lower half into
upper half until it ‘clicks’ into position.
WARNING
High voltage (103.6V nominal) exists on your Empulse; use extreme
caution when working with or around any battery terminals, cables,
bus bars, or other high voltage components.
WARNING
After reconnecting the Battery Safety Disconnect, the Empulse must
be powered on to allow for a full electrical system test and then, if
necessary, charged.
Empulse.book Page 51 Thursday, June 27, 2013 11:03 AM
