Specifications
Technical Information 91
MOTOR
TRANSMISSION AND FINAL DRIVE
BATTERIES
Type Permanent Magnet AC (PMAC) - Water Cooled
Rating:
- Power
- Max Motor Torque
Empulse:
40 kW @ 6,000 rpm (54 hp)
63 Nm (46.5 foot pounds)
Empulse R:
40 kW @ 4,500 rpm (54 hp)
90 Nm (66 foot pounds)
Current 550 amps
Transmission IET 6 speed gearbox with multi-plate, hydraulic activated wet clutch
Drive (Motor) Sprocket 14 Tooth
Driven (Rear Wheel) Sprocket 38 Tooth
Chain 520 X-ring chain (2013 models: 86 link, 2014 models: 84 link)
Battery Type Brammo Power BPM 15/90 Lithium-ion (NCM Chemistry)
Number of Modules 7
Battery Pack Capacity 9.31 kWh (nominal), 10.2 kWh (max)
Battery Pack Voltage 103.6 V (nominal)
Battery Life 1,500 cycles to 80% capacity (100% DOD)
Recharge Time Level I maximum charging time: 8 Hours. (0-99% SOC, no cell imbalances)
Level II maximum charging time: 3.5 Hours. (0-99% SOC, no cell imbalances)
