64
1. To assemble fork, place the cover guide over the inner tube so that it rests on the spring.
2. Insert the fork assembly into the fork cover until the cover guide appears in the slot in the fork cover.
3. Screw Front Fork Tool (special tool) into the top of the inner tube and pull the inner tube up through the
top of the fork cover. Temporarily tighten the fork lower bracket bolt.
4. Remove the fork tool and install the upper bracket bolt and tighten finger tight.
5. Loosen the lower bracket bolt to permit proper positioning of the inner tube and then tighten the upper
bracket bolt securely. Retighten the lower bracket bolt securely.
