5.47 CMD_CALIBRATE - execute the touch screen calibration
routine
The calibration procedure collects three touches from the touch screen, then computes
and loads an appropriate matrix into REG_TOUCH_TRANSFORM_A-F. To use it, create a
display list and then use CMD_CALIBRATE. The co-processor engine overlays the touch
targets on the current display list, gathers the calibration input and updates
REG_TOUCH_TRANSFORM_A-F.
C prototype
void cmd_calibrate( uint32_t result );
Parameters
result
output parameter; written with 0 on failure of calibration.
The completion of this function is detected when the value of REG_CMD_READ is equal
to REG_CMD_WRITE.
Command layout
+0
CMD_CALIBRATE(0xffffff15)
+4
result
Examples
cmd_dlstart();
cmd(CLEAR(1,1,1));
cmd_text(80, 30, 27, OPT_CENTER, "Please tap on the dot");
cmd_calibrate();
Code snippet 14 CMD_CALIBRATE example
