Bridgetek FT801 - Figure 10: Pixel Format for ARGB2;1555; Figure 9: Pixel Format for L1;L4;L8

FT800 Series Programmer Guide
Version 2.1
Document Reference No.: BRT_000030 Clearance No.: BRT#037
92
Product Page
Document Feedback Copyright © Bridgetek Limited
Byte Order
Pixel 0 Bit 7
Pixel 1 Bit 6
Pixel 7 Bit 0
Byte Order
Pixel 0 Bit 7-4
Pixel 1 Bit 3-0
Byte Order
Pixel 0 Bit 7-0
Byte 0
pixel 1 Bit 15-8
Byte 1
pixel 2 Bit 23-16
Byte 2
L8 format layout
L1 format layout
L4 format layout
Byte 0
Byte 0
……
Figure 9: Pixel format for L1/L4/L8
Byte Order
A Bit 7-6
R Bit 5-4
G Bit 3-2
B Bit 1-0
Byte Order
A Bit 15
R Bit 14-10
G Bit 9- 5
B Bit 4-0
ARGB2 format layout
ARGB1555 format layout
Byte 0
Byte 1
Byte 0
Figure 10: Pixel format for ARGB2/1555
