4.7 BITMAP_LAYOUT
Specify the source bitmap memory format and layout for the current handle.
Encoding
31 24
23
22
21
20
19
18 9
8 0
0x07
format
linestride
Height
Parameters
format
Bitmap pixel format. The valid range is from 0 to 11 and defined as per the
table below.
Table 7 BITMAP_LAYOUT format list
NAME VALUE
ARGB1555 0
L1 1
L4 2
L8 3
RGB332 4
ARGB2 5
ARGB4 6
RGB565 7
PALETTED 8
TEXT8X8 9
TEXTVGA 10
BARGRAPH 11
Various bitmap formats supported are:
