Byte Order
A Bit 15-12
R Bit 11-8
G Bit 7-4
B Bit 3-0
Byte Order
R Bit 7-5
G Bit 4-2
B Bit 1-0
Byte Order
R Bit 15-11
G Bit 10-5
B Bit 4-0
Byte Order
A
Bit 31-24
Byte 3
R Bit 23-16
Byte 2
G Bit 15-8
Byte 1
B Bit 7-0
Byte 0
Palette format layout
Byte 0
RGB565 format layout
Byte 1
Byte 0
ARGB4 format layout
RGB332 pixel layout
Byte 1
Byte 0
Figure 11: Pixel format for ARGB4, RGB332, RGB565 and Palette
Graphics context
None
See also
BITMAP_HANDLE, BITMAP_SIZE, BITMAP_SOURCE
